Basic Info.
Model NO.
STPGF-190
Width
57/58"
Technics
Spun-Bonded
Grade
Domestic
Material
Polyester/Fiber
Weight Range
190
Transport Package
Rolls with Pallet (or Rolls Only)
Trademark
Howell
Origin
China
Product Description
Reinforced Filament PET Nonwoven Fabric STPGF190
Technical Data
| Product Code | Mass per unit area g/m2 | Mass coeflicient of variation per unit area ( %) | Horizontal tension (N/50mm) | Longitudinal tension (N/50mm) | Elongation at break(MD) % | Elongation at break(CD) % | Moisture content (%) | Thermal dimensional stability | Distance between glassfiber(mm) |
| STPGF190 | 190 | ±10% | 500 | 650 | 32% | 38% | 0.5% | 0.3% | 7-8 |
| Standard | ISO 3374 | / | ASTM D4830 | ASTM D4830 | ASTM D4830 | ASTM D4830 | ISO 3344 | / |
Description
The regular PET nonwovens is made from polyester fiber and glassfiber. It can be used in asphalt shingle, filtration, backings, geo-textiles, etc. Good air permeability, High filtration performance, High tensile strength, Absorb sound, keep warm, absorb shock.
Characteristics
- Good air permeability
- High filtration performance
- High tensile strength
- Absorb sound, keep warm, absorb shock.
Packing
| Product Code | Mat Length (m) | Mat Width tolerance(mm) | Roll Diameter(mm) | Core Diameter(mm) |
| STPGF-170 | 1300 | ±2 | 1170 | 76/152 |
| Roll packaging: PE plastic film Pallet packaging: Pallets should NOT be stacked in more than 2 layers. | ||||
Storage
This product should be stored in a dry, ventilated, and rainproof place, with temperatures from 5ºCto 35ºC and humidity between 35% and 65%. It is recommended to be kept in the intact package when not used to avoid dampness.
