Basic Info.
Model NO.
NFC-PUE040301
Surface Treatment
PU
Weave Type
Plain Woven
Fiberglass Type
E-Glass
Alkali Content
Alkali Free
Material
Fiberglass Fabric
Processing Service
Cutting, Punching
Peak Temperature Resistance
600ºC/1112ºF
Norminal Thickness
0.4mm
Coating Content
30g
Coating Side
1 Side
Base Cloth
Fiberglass Fabric or Customized
Transport Package
Bag or Carton or Pallet
Specification
customized
Origin
Jiangsu, China
HS Code
7019590000
Product Description
Product Name: Heat Resistant thermal Insulation e glass Fiberglass Cloth with Polyurethane Coated 0.4mm Thickness Fireproof Fabric for Smoke Curtains
Brand Name: New Fire
Surface Treatment: PU
Coating Side: 1 side
Color: Multi colors are available
Thickness: 0.4mm
Weight: 460gsm(13.6oz / yd² )
Width: 0.8m - 2m or customized
Temperature Resistance: 550ºC/1022ºF
Length per Roll: Customized
Base Cloth: Fiberglass cloth, texurized fiberglass cloth, high silica cloth, steel wire reinforced Texturized fiberglass cloth, one side aluminum foil laminated fiberglass cloth
Product Details:
Product Properties:
Related Products:
Packaging & Shipment:
Our Service:
1. Free sample;
2. Custom weaves, width, length, color, surface treatment are available, the MOQ is low;
3. Package can be customized with your own LOGO;
4. High quality & Competitive price.
Any other questions, pls click "Send", we will reply you within 24 hours.
Brand Name: New Fire
Surface Treatment: PU
Coating Side: 1 side
Color: Multi colors are available
Thickness: 0.4mm
Weight: 460gsm(13.6oz / yd² )
Width: 0.8m - 2m or customized
Temperature Resistance: 550ºC/1022ºF
Length per Roll: Customized
Base Cloth: Fiberglass cloth, texurized fiberglass cloth, high silica cloth, steel wire reinforced Texturized fiberglass cloth, one side aluminum foil laminated fiberglass cloth
Product Details:
Product Properties:
1. Strong resistance to flammability
2. High chemical stability
3. Excellent abrasion resistance
4. Excellent resistance to water
5. Allergen resistant
Applications:
Insulation in expansion joints, Insulation jackets, welding blanket, fire protecting curtain, general insulation wrapping, fabric air duct, fire screen etc...
Applications:
Insulation in expansion joints, Insulation jackets, welding blanket, fire protecting curtain, general insulation wrapping, fabric air duct, fire screen etc...
Related Products:
| Product No. | Yarn Type | Coating | Thickness | Weight | |
| mm | g/m² | oz / yd² | |||
| PUE020201 | E-Glass | 1 side | 0.2 | 230 | 6.8 |
| PUE025301 | E-Glass | 1 side | 0.25 | 285 | 8.4 |
| PUE035301 | E-Glass | 1 side | 0.35 | 430 | 12.7 |
| PUE040301 | E-Glass | 1 side | 0.4 | 460 | 13.6 |
| PUE060401 | E-Glass | 1 side | 0.6 | 690 | 20.4 |
| PUE080601 | E-Glass | 1 side | 0.8 | 880 | 26.0 |
| PUE020502 | E-Glass | 2 sides | 0.18 | 260 | 7.7 |
| PUE025502 | E-Glass | 2 sides | 0.25 | 305 | 9.0 |
| PUE035602 | E-Glass | 2 sides | 0.35 | 460 | 13.6 |
| PUE040602 | E-Glass | 2 sides | 0.4 | 490 | 14.5 |
| PUE0601002 | E-Glass | 2 sides | 0.6 | 760 | 22.4 |
| PUE0801202 | E-Glass | 2 sides | 0.8 | 960 | 28.3 |
| PUT0380502 | Texturized | 2 sides | 0.38 | 330 | 9.7 |
| PUT0750602 | Texturized | 2 sides | 0.75 | 660 | 19.5 |
| PUS0250502 | High Silica | 2 sides | 0.25 | 290 | 8.6 |
| PUS0300602 | High Silica | 2 sides | 0.3 | 360 | 10.6 |
Packaging & Shipment:
Our Service:
1. Free sample;
2. Custom weaves, width, length, color, surface treatment are available, the MOQ is low;
3. Package can be customized with your own LOGO;
4. High quality & Competitive price.
Any other questions, pls click "Send", we will reply you within 24 hours.
